Antec GSK850 ATX3.1 Non-modular PSU

Manufacturer’s link for full details.

Antec GSK850 Lite AU BULK, 850W ATX3.1 PSU with 80 Plus Gold efficiency, non-modular design, 120mm silent fan, active PFC, 5-year warranty

． ATX3.1 Compatible- Meet the high standards of the ATX 3.1 standard for reliability and power efficiency
Ôºé PCIe 5.1 Compatible – The included PCIe 5.1 12V-2×6 GPU cable enables seamless compatibility with modern graphics cards
Ôºé 80 PLUS® Gold certified – Up to 92% efficient to reduce your electricity bill
Ôºé PhaseWave™ Design – A server-class LLC design with a synchronous rectification based on a DC-DC topology
Ôºé CircuitShield™ – Full suite of industrial grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
． Antec Quality 5-year warranty
． 120mm HDB Silence Fan РWhisper-quiet high-quality fluid-dynamic bearing fan with long lifetime
． Power Supply Dimension Р150(L)*140(W)*86(H)

SPECIFICATION
Model GSK850 Lite ATX3.1
Safe Model X7000A618XX-25
Type ATX 12V 3.1
Dimension 150(L)*140(W)*86(H)
Modular Non-Modular
Warranty 5 years
Input Voltage 100V-240V
Input Current 10A Max
Input Fre quency Range 50Hz-60Hz
PFC Active PFC
Power Good Signal 100-150ms
Protection OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
Output Capacity 850W
Operation Temperature 0~40°C
Regulatory cTUVus/CB/CE/FCC/ICES
Fan 120mm HDB Silent Fan
Certifications 80 Plus Gold

Connector
1 x 24(20+4)pin MB
1 x 16(12+4)pin PCIE 5.1 12V-2×6
2 x 8(4+4)pin CPU
3 x 8(6+2) Pin PCI-E
6 x SATA
2 x Molex

Shipping Box Dimensions 560mm(L)*520mm(W)*200mm(H)
Net Weight 2.10 kg
Gross Weight 2.25 kg

UPC
0-761345-20173-5 (GSK850 Lite US)
0-761345-20174-2 (GSK850 Lite
